Stylish to stand out and sleek to blend in!
Designed from the ground up using sparkie’s and end user’s feedback, it’s stacked with features to make your life a breeze!
Featuring a roomy canopy, 7-year warranty, precision speed control, low noise and not just your average remote control.
Lights, Colour, Action!
![](https://www.voltexelectrical.com.au/skins/skin_3/images2/landing_page/ceiling-fan/sec2.jpg)
![](https://www.voltexelectrical.com.au/skins/skin_3/images2/landing_page/ceiling-fan/Neat.png)
Roomy canopy for easy install.
Designed to easily fit over the fan hanging bracket, receiver, and cables with plenty of wiggle room – heaps of sparkies asked for this! The canopy screws are cleverly hidden by the magnetic cover for a neat and easy install.
Super Quiet.
The super slow sleep mode creates just enough air movement to simulate an open window or a slight breeze throughout the night while remaining super quiet.
![](https://www.voltexelectrical.com.au/skins/skin_3/images2/landing_page/ceiling-fan/quiet.png)
![](https://www.voltexelectrical.com.au/skins/skin_3/images2/landing_page/ceiling-fan/Remote.png)
Intuitive Remote Control.
For ultimate ease of use, you’ll find dedicated buttons for hassle free dimming, tri-colour adjustment, on/off. Feedback resulted in the 1, 2 and 4 hour timers included.
Easily reverse the direction of the fan for Winter mode with the single press of a button.
All with 7-year warranty. Built to last.
You’re backed up with the Voltex 7-year parts and labour warranty on the entire fitting (motor, blades, receiver, LED driver – the lot!).
![](https://www.voltexelectrical.com.au/skins/skin_3/images2/landing_page/ceiling-fan/7warranty.png)
Colours | Matte Black, Matte White |
Motor wattage | 40W |
Motor type | DC |
Air delivery | 239㎥ /min on high - 74㎥ /min on low |
Blades | 3 |
Diameter | 52” |
Blade material | ABS |
Reverse mode | Yes (via remote) |
Speed | High 220RPM – Low 71RPM |
Remote | with LED 6 speed without LED 5 speed(via remote) |
Warranty | 7 years |
Weight | 7kg |
Maximum install angle | 15 degrees |
Lumen | 90-1640lm (via remote) |
Light wattage | 20W |
Light V | 36V |
Light type | LED |
Tri colour | 2700K – 4000K – 5700K (via remote) |
Remote frequency | Nominal 434MHz |
Depth from Ceiling | 298mm |
Installation area | Indoor, Covered outdoor |
Base diameter | 150mm |
- Light will not come on automatically when power interruption occurs
- Light will only change colour temperature when the Tricolour button is pressed
Pairing a New Remote to the fan:
- Ensure Remote has batteries fitted & power to wall switch is on.
- Turn wall switch off for minimum 10 seconds.
- Turn wall switch back on- The fan should emit a short "beep" sound.
- Press & hold the "ON" button on the remote & continue to hold until a double "beep" is heard.
- Release the button.
Remote should now be paired & old remote automatically unpaired.
